About the Client
Anonymous Swiss Client: Swiss Bank
Challenge
The client faced the complex challenge of monitoring a distributed and complex system. The market data platform consisted of approximately 30 components, including a central component based on the Solace Event Broker and third-party software. This led to delays in error detection and potential data loss.
- Distributed Architecture: The market data platform was spread across multiple Red Hat OpenShift clusters and network zones.
- Complexity: The overall system consisted of around 30 individual components, including third-party software.
- Lack of Monitoring: A comprehensive, centralized monitoring system did not exist. Monitoring was primarily assigned to application management.
Solution Approach
To address these challenges, we adopted a standards-based approach that seamlessly integrated into the client’s existing OpenShift environment. Since Prometheus-based monitoring was already used on the OpenShift platform, no additional licensing costs were incurred, and the open solution provided maximum flexibility.
- OpenShift Monitoring Stack (Prometheus): Built on the OpenShift-integrated monitoring stack, which includes Prometheus, Alertmanager, and Grafana, we established a centralized monitoring solution.
- Helm & ArgoCD: The deployment of all monitoring components was automated and reproducible via ArgoCD and Helm.
- Kubernetes & Application Monitoring: In addition to generic Kubernetes rules for infrastructure monitoring (CPU, memory, pod status, etc.), specific service monitors and Prometheus rules were defined for each individual component of the market data platform.
- Business Monitoring: In addition to technical monitoring, business metrics were also integrated into Prometheus. This enabled the monitoring of business processes and alerts in case of business errors.
- AlertmanagerConfig: A complex Alertmanager configuration was implemented to define detailed alerting rules and mute intervals. A total of around 30 Prometheus rules were established.
Results
The implemented monitoring solution led to measurable improvements and qualitative benefits for the client:
- Increased Operational Security: Comprehensive monitoring was a critical factor in the successful introduction of the market data platform and ensured its operational security.
- Standardization: By leveraging the OpenShift Monitoring Stack as the foundation, the solution is easily extendable and can serve as a blueprint for future monitoring requirements.
- Central Monitoring Platform: The solution enables global integration into the existing monitoring platform.
- End-to-End System Monitoring: The monitoring platform now oversees all technical and business components.
- Cost Reduction: The implementation and operational costs of the monitoring solution were significantly reduced.
Client Statement
Although we are not allowed to use a formal quote, this LinkedIn post humorously expressed their satisfaction: «Du hast uns sprichwörtlich den A…. gerettet. Top Job!»
Conclusion & Lessons Learned
This project confirmed that the OpenShift Monitoring Stack provides an excellent foundation for application monitoring. Key takeaways include:
- OpenShift Monitoring as a Foundation: The OpenShift Monitoring Stack offers a solid base for comprehensive application monitoring in OpenShift environments.
- Domain Expertise for Business Monitoring: Integrating business metrics requires deep domain knowledge and close collaboration with business departments.
- Complexity of AlertmanagerConfig: Extensive Alertmanager configurations can quickly become complex and require expertise in maintenance and rule management.
- Avoiding Alert Fatigue: An iterative approach to alert configuration is essential. Alerts must be actionable, intelligent, and urgent to avoid being ignored.
- Prometheus Monitoring Stack Delivers: The Prometheus Monitoring Stack has proven to be a powerful and flexible solution.
